Asus ROG Strix B550-F Gaming AM4 ATX Motherboard

Asus ROG Strix B550-F Gaming AM4 ATX Motherboard

ROG Strix B550 Gaming series motherboards offer a feature-set usually found in the higher-end ROG Strix X570 Gaming series, including the latest PCIe 4.0. With robust power delivery and effective cooling, ROG Strix B550 Gaming is well-equipped to handle 3rd Gen AMD Ryzen CPUs. Boasting futuristic aesthetics and intuitive ROG software, ROG Strix B550-F Gaming gives you a head start on your dream build. ROG Strix B550-F Gaming is PCIe 4.0-ready and provides the latest connectivity options for supersmooth networking and blisteringly fast file transfers. Audio enhancements give you a massive advantage, allowing you to pick up on the subtlest of cues for a completely immersive gaming experience.

ROG Strix B550-F Gaming features two M.2 slots, one of which supports the latest PCIe 4.0 standard to provide maximum storage flexibility and the fastest data speeds available via the 3rd Gen AMD Ryzen platform. Both M.2 slots support up to the type 22110 socket and NVM Express RAID for a performance boost. Onboard 2.5 Gb Ethernet gives your wired connection a boost, with speeds that are 2.5 times faster than standard Ethernet connections for speedy file transfers, lag-free gaming, and high-res video streaming. Built-in ROG SupremeFX audio technology ensures pristine audio for ROG Strix B550-F Gaming. Along with ensuring a flat frequency response for a neutral, detailed sound signature, it offers two front-panel outputs driven by op-amps that deliver high-quality audio to gaming headsets.

ROG Strix B550-F Gaming provides robust power delivery to fuel Ryzen’s cores, comprehensive cooling, and support for faster memory — so it has everything you need to load up your build with high-performance components for playing in the big leagues. Digital power control and an array of power stages ensure ROG Strix B550-F Gaming has the muscle to control the latest AMD CPUs. The ProCool socket is built to exacting specifications to ensure flush contact with the PSU power lines, enabling lower impedance and better heat dissipation. ASUS DIGI+ Power Control is an innovative set of controllers for digital VRM and DRAM Voltage.

These controllers offer ultra-precise memory and voltage tuning for optimal system efficiency, stability, and performance. 12+2 power stages combine high-side and low-side MOSFETs and drivers into a single package, delivering the power and efficiency that the AMD CPUs demand. Superior chokes and durable capacitors are engineered to resist extreme temperatures and provide up to 110% better performance than the industry standard. The 6-layer PCB quickly dissipates heat around the VRM to improve overall system stability and give the CPU more overclocking headroom. The cyberpunk-inspired aesthetics of ROG Strix B550-F Gaming are accentuated by the bold slashes and cybertext. By pairing your rig with other products from the diverse ROG ecosystem, you can create a fully customized gaming setup that reflects your personal style.

Asus ROG Strix B550-F Gaming Review

We review the new STRIX B550-F Gaming Wi-Fi motherboard from ASUS. This board is aimed and priced in a more mainstream fashion but still is fitted with features like AX WIFI6 and 2.4 GigE as well as a set of M2 SSD slots.

All Ryzen processors Gen processors are supported on this board. An 8+4 pin dual pin connector already indicates a strong VRM, and this motherboard as such has 12+2 phases. ASUS applies a somewhat more simplified shielded design, optimized for cooling, and armed with a proper feature set for that Ryzen processor. It also has and has nice hidden M2 slots, two of them. The motherboard has been fitted with the usual suspects and then some, including a 2.5 Gigabit (Intel) ethernet and then WIFI6 in the form of AX. When it comes to audio you will run into an ALC 1220 Codec from Realtek. B550, believe it or not, the B series typically are business (quick add-in) motherboards, or for consumers, we refer to it as the B for budget. Alongside the Ryzen 3 3000 series, there is X570, and now a B550 chipset for socket AM4 processors. PCI Gen 4.0 still is applied to the x16 slot and one M2 slot (the processor provides it (you need a Ryzen 3000 processor for PCIe Gen 4.0, older procs will offer PCIe Gen 3.0). The B550 chipset and DMI uplink otherwise are all PCIe Gen 3.0.

Little about the ASUS ROG Strix B550-F Gaming [WI-FI] can be referred to as ‘budget’ though, as this easily could be a premium motherboard due to its features and a BD price tag. The board as stated is positioned in an higher end region of what is considered the mainstream segment, it does look properly STRIX styled, stuff we like of course. Also, the new board has some interesting new features Have a peek, and then let’s head onwards into the review my man.

Specification:
