Sale!
ASUS TUF GAMING Z790-PLUS WIFI 12TH/13TH GEN ATX MOTHERBOARD
Original price was: 51,200.00৳ .47,500.00৳ Current price is: 47,500.00৳ .
- Supported CPU: 13th Gen & 12th Gen Processors (LGA1700)
- Supported RAM: 4 X DIMM, Max. 128GB, DDR5
- Graphics Output: 1 X DisplayPort, 1 X HDMI
- Features: Wi-Fi 6, Bluetooth V5.2
| Processor | |
| Supported CPU | Intel® Socket LGA1700 For 13th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold And Celeron® Processors* Supports Intel® Turbo Boost Technology 2.0 And Intel® Turbo Boost Max Technology 3.0** * Refer To Www.Asus.Com For CPU Support List. ** Intel® Turbo Boost Max Technology 3.0 Support Depends On The CPU Types. |
| Mainboard | |
| Chipset | Intel® Z790 Chipset |
| Memory | |
| Memory | 4 X DIMM, Max. 128GB, DDR5 7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-Buffered Memory* Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) OptiMem II * Supported Memory Types, Data Rate (Speed), And Number Of DRAM Modules Vary Depending On The CPU And Memory Configuration, For More Information Please Refer To CPU/Memory Support List Under The Support Tab Of Product Information Site Or Visit Https://Www.Asus.Com/Support/ |
| Storage | |
| Supported Storage | Total Supports 4 X M.2 Slots And 4 X SATA 6Gb/S Ports* Intel® 13th & 12th Gen Processors M.2_1 Slot (Key M), Type 2242/2260/2280/22110 – Intel® 13th & 12th Gen Processors Support PCIe 4.0 X4 Mode Intel® Z790 Chipset M.2_2 Slot (Key M), Type 2242/2260/2280 (Supports PCIe 4.0 X4 Mode) M.2_3 Slot (Key M), Type 2242/2260/2280/22110 (Supports PCIe 4.0 X4 Mode) M.2_4 Slot (Key M), Type 2242/2260/2280 (Supports PCIe 4.0 X4 & SATA Modes) 4 X SATA 6Gb/S Ports * Intel® Rapid Storage Technology Supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10. |
| Graphics | |
| Graphics | 1 X DisplayPort** 1 X HDMI® Port*** * Graphics Specifications May Vary Between CPU Types. Please Refer To Www.Intel.Com For Any Updates. ** Supports Max. 4K@60Hz As Specified In DisplayPort 1.4. *** Supports 4K@60Hz As Specified In HDMI 2.1. **** VGA Resolution Support Depends On Processors’ Or Graphic Cards’ Resolution. 1 X DisplayPort** 1 X HDMI® Port*** * Graphics Specifications May Vary Between CPU Types. Please Refer To Www.Intel.Com For Any Updates. ** Supports Max. 4K@60Hz As Specified In DisplayPort 1.4. *** Supports 4K@60Hz As Specified In HDMI 2.1. **** VGA Resolution Support Depends On Processors’ Or Graphic Cards’ Resolution. |
| Audio & Microphone | |
| Audio | Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC* – Impedance Sense For Front And Rear Headphone Outputs – Internal Audio Amplifier To Enhance The Highest Quality Sound For Headphone And Speakers – Supports: Jack-Detection, Multi-Streaming, Front Panel Jack-Retasking – High Quality 120 DB SNR Stereo Playback Output And 113 DB SNR Recording Input (Line-In) – Supports Up To 32-Bit/192 KHz Playback*” Audio Features – Audio Shielding – Rear Optical S/PDIF Out Port – Premium Audio Capacitors – Dedicated Audio PCB Layers – Audio Cover * Due To Limitations In HDA Bandwidth, 32-Bit/192 KHz Is Not Supported For 7.1 Surround Sound Audio. |
| Networking & Connectivity | |
| LAN | 1 X Intel® 2.5Gb Ethernet TUF LANGuard |
| WiFi | Wi-Fi 6E 2×2 Wi-Fi 6E (802.11 A/B/G/N/Ac/Ax) Supports 2.4/5/6GHz Frequency Band |
| Bluetooth | Bluetooth® V5.3 |
| Ports | |
| Slots | Intel® 13th & 12th Gen Processors* 1 X PCIe 5.0 X16 Slot Intel® Z790 Chipset 1 X PCIe 4.0 X16 Slot (Supports X4 Mode) 1 X PCIe 4.0 X4 Slot 2 X PCIe 3.0 X1 Slots * Please Check The PCIe Bifurcation Table At The Support Site (Https://Www.Asus.Com/Support/FAQ/1037507/). – To Ensure Compatibility Of The Device Installed, Please Refer To Https://Www.Asus.Com/Support/ For The List Of Supported Peripherals. |
| Internal I/O Ports | Fan And Cooling Related 1 X 4-Pin CPU Fan Header 1 X 4-Pin CPU OPT Fan Header 1 X 4-Pin AIO Pump Header 4 X 4-Pin Chassis Fan Headers Power Related 1 X 24-Pin Main Power Connector 2 X 8-Pin +12V Power Connectors Storage Related 4 X M.2 Slots (Key M) 4 X SATA 6Gb/S Ports USB 1 X USB 3.2 Gen 2 Connector (Supports USB Type-C®) 1 X USB 3.2 Gen 1 Header Supports 2 Additional USB 3.2 Gen 1 Ports 2 X USB 2.0 Headers Support Additional 4 USB 2.0 Ports Miscellaneous 3 X Addressable Gen 2 Headers 1 X Aura RGB Header 1 X Clear CMOS Header 1 X COM Port Header 1 X Front Panel Audio Header (AAFP) 1 X 20-3 Pin System Panel Header With Chassis Intrude Function 1 X Thunderbolt™ (USB4®) Header |
| External I/O Ports | 1 X USB 3.2 Gen 2×2 Port (1 X USB Type-C®) 3 X USB 3.2 Gen 2 Ports (2 X Type-A + 1 X USB Type-C®) 4 X USB 3.2 Gen 1 Ports (4 X Type-A) 1 X DisplayPort 1 X HDMI® Port 1 X Wi-Fi Module 1 X Intel® 2.5Gb Ethernet Port 5 X Audio Jacks 1 X Optical S/PDIF Out Port |
| USB | Rear USB (Total 8 Ports) 1 X USB 3.2 Gen 2×2 Port (1 X USB Type-C®) 3 X USB 3.2 Gen 2 Ports (2 X Type-A + 1 X USB Type-C®) 4 X USB 3.2 Gen 1 Ports (4 X Type-A) Front USB (Total 7 Ports) 1 X USB 3.2 Gen 2 Connector (Supports USB Type-C®) 1 X USB 3.2 Gen 1 Header Supports 2 Additional USB 3.2 Gen 1 Ports 2 X USB 2.0 Headers Support Additional 4 USB 2.0 Ports |
| HDMI | 1 X HDMI® Port |
| Technical Info | |
| BIOS | 192 (128+64) Mb Flash ROM, UEFI AMI BIOS |
| Special Features | |
| Special Features | ASUS TUF PROTECTION – DIGI+ VRM (- Digital Power Design With DrMOS) – ESD Guards – TUF LANGuard – Overvoltage Protection – Safeslot – Stainless-Steel Back I/O ASUS Q-Design – M.2 Q-Latch – PCIe Slot Q-Release – Q-DIMM – Q-LED (CPU [Red], DRAM [Yellow], VGA [White], Boot Device [Yellow Green]) – Q-Slot ASUS Thermal Solution – M.2 Heatsink – VRM Heatsink Design ASUS EZ DIY – CPU Socket Lever Protector – ProCool – Pre-Mounted I/O Shield – SafeDIMM AURA Sync – Aura RGB Header – Addressable Gen 2 Headers |
| Software Features | ASUS Exclusive Software Armoury Crate – Aura Creator – Aura Sync – Fan Xpert 4 (With AI Cooling II) – Two-Way AI Noise Cancelation – Power Saving AI Suite 3 – TurboV EVO – DIGI+ VRM – PC Cleaner TUF GAMING CPU-Z DTS Audio Processing MyAsus Norton 360 For Gamers WinRAR UEFI BIOS ASUS EZ DIY – ASUS CrashFree BIOS 3 – ASUS EZ Flash 3 – ASUS UEFI BIOS EZ Mode |
| Physical Specification | |
| Form Factor | ATX Form Factor 12 Inch X 9.6 Inch ( 30.5 Cm X 24.4 Cm ) |
| Others | |
| Other Features | Manageability: WOL By PME, PXE Operating System: Windows® 11, Windows® 10 64-Bit |
| Warranty Information | |
| Warranty | 3 Years |
