Specification
| Case Type | |
| Type | Mid Tower |
| Front Panel | USB3.0×1、USB2.0×1、Audio×1 |
| Tempered Glass Panel | FULL-SIZED TEMPERED GLASS WINDOW |
| Motherboard Support | Mini-ITX / Micro-ATX / ATX |
| External Features | |
| Color(s) | Black |
| Material | ABS+SPCC+Tempered Glass |
| Weight | 5.25Kg |
| Dimensions | 416×210×477mm(L×W×H) |
| Front Ports | USB3.0×1, USB2.0×1, Audio×1 |
| Expansion Slots | 7 Slots |
| Radiator Support | Additional Radiator support Front: 120/140/240/280/360mm; Top: 120/240mm; Rear: 120mm |
| Fan Support | Front: 3×120 / 2×140mm Top: 2×120 / 2×140mm Rear: 1×120mm |
| Pre- Installed Fans | Front: 3×120mm Rear: 1×120mm |
| Drive Bays | 3.5″ Drive Bays 2 2.5″ Drive Bays 2+1 |
| I/O Port | USB3.0×1、USB2.0×1、Audio×1 |
| Clearance Space | |
| Maximum CPU Cooler Height | 163mm |
| Maximum PSU Length | Max PMax PSU Length: 170mmSU Length: 170mm |
| Warranty | |
| Warranty | No Warranty |
DeepCool CC560 Tempered Glass Mid-Tower ATX Case
The DeepCool CC560 Mid-Tower Case offers outstanding value with broad component compatibility, a full-sized tempered glass window, and four pre-installed LED fans to kickstart any project. The CC560’s chassis is highly ventilated throughout, with an airflow front panel and a broad mesh top panel to keep the fresh air moving. Four pre-installed LED fans to provide high airflow performance, ensuring that any system configuration has the top-tier cooling capability. Enough space in front for 360mm radiators or 240mm on top for high-performance AIO liquid cooling. Up to 6x 120mm or 4x, 140mm cooling fans can be supported. Maximum Height of CPU Cooler: 163mm Maximum Length of GPU: 370mm The maximum length of the power supply is 170mm. Install up to two 2.5″ SSDs directly on the backplate and two 3.5″ HDDs behind the shroud in a removable drive cage for further versatility.
The DeepCool CC560 Mid-Tower Case has no warranty.
