Specification:
Basic Information | ||
Supported CPU | Supports 6th/7th Gen Intel Core i3/i5/i7 processors, and Intel Pentium and Celeron processors for Socket LGA1151 | |
Chipset | Intel B250 Chipset | |
Form Factor | 9.6 in. x 9.0 in. (24.4 cm x 22.8 cm) M-ATX Form Factor |
|
Expansion Slots | ||
PCI | 1 x PCIe 3.0 x16 slots 2 x PCIe 3.0 x1 slots |
|
M.2 Socket | 1 x M.2 slots (Key M) Support up to PCIe 3.0 x4 and SATA 6Gb/ Supports 2242/ 2260/ 2280 storage devices |
|
Memory | ||
Type | 2 x DDR4 memory slots | |
Slots | 2 x DDR4 memory slots | |
Supported Memory | 7th Gen processors support DDR4 2400/ 2133 MHz 6th Gen processors support DDR4 2133 MHz Supports non-ECC, un-buffered memory Supports Intel Extreme Memory Profile (XMP |
|
Maximum Mamory | 32GB | |
Graphics | ||
Graphics | 1 x DVI-D port, supports a maximum resolution of 1920×1200@60Hz 1 x VGA port, supports a maximum resolution of 2048×1536@50Hz, 2048×1280@60Hz, 1920×1200@60Hz |
|
Connector & Ports | ||
USB (s) | Intel B250 Chipset 6 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connector) 6 x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connectors) |
|
LAN Port (s) | 1 x Realtek RTL8111H Gigabit LAN controller | |
Supported Storage | Intel B250 Chipset • 6 x SATA 6Gb/s ports • 1 x M.2 slots (Key M) – Support up to PCIe 3.0 x4 and SATA 6Gb/ – Supports 2242/ 2260/ 2280 storage devices – Intel Optane Memory Ready – Support PCIe 3.0 x4 NVMe U.2 SSD with Turbo U.2 Host card |
|
Audio | Realtek ALC887 Codec 7.1-Channel High Definition Audio |
|
Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 6 x SATA 6Gb/s connectors 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector 1 x Front panel audio connector 2 x Front panel connectors 1 x Chassis Intrusion connector 1 x Serial Port connector 1 x Clear CMOS jumper |
|
DVI-D (s) | 1 x DVI-D port, supports a maximum resolution of 1920×1200@60Hz | |
Warranty Information | ||
Manufacturing Warranty | 03 years | |
Others | ||
Special Features | 1 x VGA port, supports a maximum resolution of 2048×1536@50Hz, 2048×1280@60Hz, 1920×1200@60Hz |
What is the best price of MSI B250M PRO-VD MOTHERBOARD in Bangladesh?
Buy MSI B250M PRO-VD MOTHERBOARD at Best Price in Bangladesh
You can Also buy economical and best components from Creatus Computer. Shop online by browsing through our extensive collection of components at Creatus Computer. Our online store’s products are from some of the most well-known brands, such as Acer, Asus, Dell, Hp, Avita, Lenovo, Apple, Msi, Gigabyte, Razer, I-Life, Xiaomi, Walton, Chuwi, 1More, AFOX , AMD, Antec , AOC, Aorus, Apacher, AsRock, AULA, Avita, Bdracer, BenQ, Boya, Brother, Cannon, Casio, Chuwi, Colorful, Cooler Master, Corsair, Couger, Creative, D-Link, Dell, Edifier, Elgato, Epson, G.Skill, Galax, Gamdias, GeIL, Genius, Gigabyte, Havit, Hikvision, HOCO, Hp, Huawei, HyperX, I-Life, Intel, Jabra, JBL, Kingston, Lenovo, Lexar, LG, Logitech, Micro Pack, MotoSpeed, Msi, Net Gear, Nvidia, Patriot, Philips, PNY, Power Color, Radeon, Ramsta, RAPOO, Razer, Realme, Remax, Ryzen, Samsung, Sapphire, Segate, Sky View, SteelSeries, Team, Tenda, Thearmaltake, Toshiba, Toto Link, TP-Link, Transcend, TwinMos, Uiisii, Value Top, View Sonic, Walton, Western Digital, XFX, Xiaomi, Zotac and many more. All these component like Casing, Graphics Card, IPS & UPS, Monitor, Motherboard, Power Supply, Processor, Ram, SSD, HDD, Optical Disk Drive, Cpu Cooler, Cooling Fan Etc are available varied configurations and sizes just according to your requirements, Here at Creatus Computer you can find out the prices of all brand pc component. So if you want to buy the latest and best component of pc, but have refrained yourself because of the prices, this is your chance to pick up a product at the most profitable costs. Shop with us with and find the best computer components you are looking for buy.
