MSI H310M PRO-VDH Plus Intel 9th Gen Motherboard
6,200.00৳
Key Features
• Supports 9th / 8th Gen Intel Core / Pentium Gold / Celeron processors for LGA 1151
• X-Boost & Core Boost
• EZ Debug LED: For troubleshoot
• Audio Boost: studio grade sound
MSI H310M PRO-VDH Plus Intel 9th Gen Motherboard
Cooling your PC is essential for reliable performance. We’ve made sure to include enough fan headers with full control to allow you to cool your system to the max. Supporting the latest display connectors for new technologies (OLED, HDR) and legacy connectors for beamers, MSI motherboards are designed to make life easier for any professional user. Enjoy awesome 4K UHD (2160p ultra-high definition) video playback with MSI motherboards. This motherboard is equipped with a HDMI port supporting the latest 4K Ultra-HD 4096×2160p resolution @ 24Hz to provide a breathtaking visual experience. Get the most immersive sound experience. MSI Audio Boost delivers the highest sound quality through the use of premium quality audio components.
Specifications:
| Basic Information | ||
| Supported CPU | Supports 9th / 8th Gen Intel Core / Pentium Gold / Celeron processors for LGA 1151 socket | |
| Chipset | Intel H310 Chipset | |
| Form Factor | 8.9 in. x 7.3 in. (22.6 cm x 18.5 cm) m-ATX Form Factor |
|
| Expansion Slots | ||
| PCI | 1 x PCIe 3.0 x16 slot 2 x PCIe 2.0 x1 slots |
|
| Memory | ||
| Type | Supports Dual-Channel mode | |
| Slots | 2 x DDR4 memory slots | |
| Supported Memory | DDR4 2666/ 2400/ 2133 MHz (by JEDEC) DDR4 2666/ 2400/ 2133 MHz (by XMP OC) non-ECC, un-buffered memory Intel Extreme Memory Profile (XMP) |
|
| Maximum Mamory | 32GB | |
| Graphics | ||
| Graphics | 1 x VGA port, supports a maximum resolution of 2048×1536@50Hz, 2048×1280@60Hz, 1920×1200@60Hz DVI-D port, supports a maximum resolution of 1920×1200@60Hz 1 x HDMI™ port, supports a maximum resolution of 4096×2160@30H |
|
| Connector & Ports | ||
| HDMI | 1 x HDMI port, supports a maximum resolution of 4096×2160@30H | |
| USB (s) | 4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector) 6 x USB 2.0 (High-speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connector) |
|
| LAN Port (s) | 1 x RTL8111H Gigabit LAN controller | |
| Supported Storage | Intel H310 Chipset 4 x SATA 6Gb/s ports Supports Intel® Rapid Storage Technology |
|
| Audio | Realtek ALC887/ALC892 Codec 7.1-Channel High Definition Audio |
|
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) USB 2.0 connector (supports additional 2 USB 2.0 ports) 1 x Clear CMOS jumper 2 x Front panel connectors 1 x Serial port connector TPM module connector 1 x Chassis Intrusion connector Front panel audio connector 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector |
|
| DVI-D (s) | 1 x DVI-D port, supports a maximum resolution of 1920×1200@60Hz | |
| Warranty Information | ||
| Manufacturing Warranty | 03 years | |
